Inputs:

ADC : 96kHz, 32-bit Delta-Sigma
Mic/Line XLR Inputs : Balanced XLR, +48V phantom power
Mic/Line Preamp : Fully recallable
Input Sensitivity (dLive) : -60 to +15dBu
Input Sensitivity (SQ) : -60 to +20dBu
Analogue Gain (dLive) : +5 to +60dB, 1dB steps
Analogue Gain (SQ) : 0 to +60dB, 1dB steps
Pad : -20dB Active PAD
Maximum Input Level : +38dBu (PAD in)
Input Impedance : >4kΩ (Pad out), >10kΩ (Pad in)
Mic EIN : -127.5dBu with 150Ω source
Phantom Power indication : Per socket, internal or external phantom power sensing, triggered at 24V
Measured Prime in to AES out, 20-20kHz, minimum Gain, Pad out.
Full Signal Dynamic Range : 114.8dB
Noise at 0dB gain : -96.8dBu

Frequency Response to AES output

At 0dB gain : 10Hz - 20kHz +0/-0.3dB
At 30dB gain : 10Hz - 20kHz +0/-0.3dB
At 60dB gain : 10Hz - 20kHz +0/-0.25dB

THD+N (analogue in to AES out)

0.0009% @ +10dBu out 0dB gain
0.0009% @ +10dBu out 10dB gain
0.001% @ +10dBu out 20dB gain
0.0011% @ +10dBu out 30dB gain

Outputs:

DAC : 96kHz, 32-bit Delta-Sigma

Analogue XLR Outputs:

Output Impedance : <60Ω
Nominal Output : +4dBu = 0dB meter reading
Maximum Output Level : +22dBu
Residual Output Noise : -94dBu (22-22kHz)
THD+N : -105dB (22-22kHz) @1kHz
Crosstalk separation : -94dBu (22-22kHz) @1kH
