SPECIFICATIONS
Model AH3X6PRO
Type Active PA Cabinet
Frequency Response 55Hz - 20000Hz (-10dB) 60Hz - 18000Hz (-3dB)
LF Driver 3x 6.5-inch HH designed high performance driver
HF Driver 1inch compression driver
Coverage 80° x 80° Max SPL 1m2 118 dB SPL Continuous, 125 dB SPL Peak
Controls Channel 1 Level, Channel 2 Level, Bass, Treble, Volume Input
Connectors 2x Balanced XLR Connectors with Mic/Line switch. 2x 6.3mm Line Level jack inputs. 1x Stereo 3.5mm Jack input. Media Player with Bluetooth 5.0, USB and SD Card
Output Connectors 1x Balanced XLR Mix Out
Input Impedance 100K Balanced Line, 1K Mic, 10K unbalanced
Signal Indicators Power, Clip Indicator
Amplifier
System Amplifier
Power Rating 400W Peak
Amplifier Type Class A/B
Power Supply Linear Low Noise Toroidal PSU with switchable mains voltage
Protection Comprehensive protection and clip free limiting + clip indicator
Enclosure
Acoustically optimised 15mm MDF cabinet
Heavy duty black vinyl covering with metal corner protectors
Integrated rear carry pocket handle
Powder coated front grille with
Bottom 35mm Pole Mount Socket
Power Requirements
AC Power 100V-120V~ OR 220-240V~ 50/60Hz User Switchable
Power Inlet IEC C14 Inlet Typical
Power Consumption 320W
Other
Unit dimensions (HWD) 720 x 205 x 230mm, (28.3" x 8.1" x 9.1")
Unit weight 9.7Kg, (21.4 lbs)
Carton dimensions (HWD) 805 x 285 x 260mm, (31.7" x 11.2" x 10.2") , 0.06 M3
Packed Weight 14.9Kg, (32.8 lbs) EAN
Code 5060109458800
