Features:
- Complete set – includes all components needed to start with wireless in-ear monitoring
- Reliable, easy-to-manage wireless connection in the professional UHF range
- Multiple audio modes for varying setups or performances and unique mixing options
- Focus mode allows the ability to prioritize one input over another directly from the bodypack receiver for a user-specific monitoring experience
- Advanced features like EQ and limiter
- Perfectly aligned frequency presets in 8 banks with 12 channels each – option for manual tuning
- An unlimited number of receivers can be used with one transmitter, allowing for cost-effective setups
- Infrared sensor to sync multiple receivers easily to one transmitter
The all-in-one starter kit on a pro level
Switching to in-ear monitoring is no longer overwhelming or needs lengthy equipment lists. The XS Wireless IEM set includes everything to get you started. You can now have the best near-field sound, full control of your mix, and good isolation, along with a rock-solid wireless connection. Focus on your new live sound on any stage or venue: XS Wireless IEM connects you to a set of rich options that leads talents on all stages to new levels of perfection. It’s that easy.
Adapts to any situation and setup
Are you a solo talent with a guitar and laptop? A duo with changing instruments, or a larger band, or somehow all of that? The XS Wireless IEM set has you covered. Every receiver can balance an individual mix thanks to its multiple audio modes and balancing options. Also, you can easily set up your whole band by simply linking additional receiver bodypacks to your transmitter.
It’s not about sound alone
Yes, XS Wireless IEM uses an advanced UHF design to deliver a reliable, clear sound – and the IE 4 in-ear headphones offer all the dynamics and bass levels. But there’s more. We’ve condensed decades of experience from stages big and small into the development of XS Wireless IEM. Most can be heard. Some can be felt. And others will only come to your attention once you need them. But all of them will guide you safely, whether live on stage or during lengthy rehearsal sessions.
XSW IEM EK Stereo Receiver
Frequency range
A 476-500 MHz
B 572-596 MHz
C 662-686 MHz
E 823,2-831,8 MHz
K 925,2-937,3 MHz
- Dimensions: Approx. 95 x 70 x 26 mm
- Weight (incl. batteries): ca. 110 g
- Switching bandwidth up to 24 MHz
- Temperature Range: 0 °C to +40 °C
- AF frequency response: 45 Hz to 15 kHz
- Modulation: Wideband FM
- Signal-to-noise ratio (1 mV, peak deviation): ≥88 dB
- AF output level at 3.5 mm: 2 x 1,25 Veff at 16 Ω
- High Boost (EQ): +10 dB at 13 kHz
- Total harmonic distortion (THD): ≤ 1 %
- Limiter: -10 dB
- Power supply: 2 AA batteries, 1.5 V
- Operating time: Approx. 6 hrs
XSW IEM SR Stereo Transmitter
Frequency Ranges (RF Output Power)
A 476-500 MHz (30 mW)
B 572-596 MHz (30 mW)
C 662-686 MHz (30 mW)
E 823,2-831,8 MHz (30 mW)
K 925,2-937,3 MHz (10 mW)
- Dimensions: Approx. 200 x 128 x 42 mm
- Weight: Approx. 700 g
- Switching bandwidth up to 24 MHz
- Temperature Range: 0 °C to +40 °C
- AF frequency response: 45 Hz to 15 kHz
- Modulation: FM Stereo
- Signal-to-noise ratio (at nominal load and peak deviation): ≥88 dB
- Current consumption: Approx. 400mA (depending on volume level)
- Input rating: +12 V DC
- Input: 2x XLR-3/¼" (6.3 mm) jack combo socket, electronically balanced
- Antenna Output: BNC socket, 50 Ω
XSW IEM EK Stereo Receiver
Frequency range
A 476-500 MHz
B 572-596 MHz
C 662-686 MHz
E 823,2-831,8 MHz
K 925,2-937,3 MHz
- Dimensions: Approx. 95 x 70 x 26 mm
- Weight (incl. batteries): ca. 110 g
- Switching bandwidth up to 24 MHz
- Temperature Range: 0 °C to +40 °C
- AF frequency response: 45 Hz to 15 kHz
- Modulation: Wideband FM
- Signal-to-noise ratio (1 mV, peak deviation): ≥88 dB
- AF output level at 3.5 mm: 2 x 1,25 Veff at 16 Ω
- High Boost (EQ): +10 dB at 13 kHz
- Total harmonic distortion (THD): ≤ 1 %
- Limiter: -10 dB
- Power supply: 2 AA batteries, 1.5 V
- Operating time: Approx. 6 hrs
XSW IEM SR Stereo Transmitter
Frequency Ranges (RF Output Power)
A 476-500 MHz (30 mW)
B 572-596 MHz (30 mW)
C 662-686 MHz (30 mW)
E 823,2-831,8 MHz (30 mW)
K 925,2-937,3 MHz (10 mW)
- Dimensions: Approx. 200 x 128 x 42 mm
- Weight: Approx. 700 g
- Switching bandwidth up to 24 MHz
- Temperature Range: 0 °C to +40 °C
- AF frequency response: 45 Hz to 15 kHz
- Modulation: FM Stereo
- Signal-to-noise ratio (at nominal load and peak deviation): ≥88 dB
- Current consumption: Approx. 400mA (depending on volume level)
- Input rating: +12 V DC
- Input: 2x XLR-3/¼" (6.3 mm) jack combo socket, electronically balanced
- Antenna Output: BNC socket, 50 Ω
NT 12-5CW Power supply
- Input voltage range: 100 to 240 V~200mA, 50/60 Hz
- Storage temperature: -20 °C ... +60 °C (4 °F ... +140 °F)
- Output voltage: +12 V DC
- Temperature Range: 0 °C ... +40 °C (32 °F ... +104 °F)
- Current consumption: Max. 200 mA
- Secondary output current: 500 mA
