NECK
NECK MATERIAL : Maple
NECK FINISH : Satin Urethane with Gloss Urethane Headstock Face
NECK SHAPE : Modern "D"
NECK CONSTRUCTION : 4-Bolt Standard
FINGERBOARD RADIUS : 10" to 14" Compound Radius (254 mm to 355.6 mm)
FINGERBOARD MATERIAL : Maple
POSITION INLAYS : Black Pearloid Dots
NUMBER OF FRETS : 22
TRUSS ROD : Bi-Flex™
STRING NUT : Bone
NUT WIDTH : 1.685" (42.8 mm)
NUT MATERIAL : Bone
BODY
BODY : Alder
BODY FINISH : Gloss Urethane
BODY SHAPE : Telecaster®
BODY BINDING : Cream
BODY STYLE : Solid Body
BODY MATERIAL : Alder
HARDWARE
BRIDGE : 6-Saddle American Tele® with Chromed Brass Saddles
PICKGUARD : 3-Ply Mint Green
CONTROL KNOBS : Knurled Flat-Top
SWITCH TIP : Black
HARDWARE FINISH : Nickel/Chrome
TUNING MACHINES : Deluxe Cast/Sealed Locking (all short posts)
STRINGS : Fender® USA 250L Nickel Plated Steel (.009-.042 Gauges), PN 0730250403
NECK PLATE : 4-Bolt Asymmetrical
STRAP BUTTONS : Locking
ELECTRONICS
BRIDGE PICKUP : Ultra Noiseless™ Vintage Tele®
NECK PICKUP : Ultra Noiseless™ Vintage Tele®
PICKUP CONFIGURATION : SS
CONTROLS : Master Volume (S-1™ Switch), Master Tone
SWITCHING : 3-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
SPECIAL ELECTRONICS : S-1™ Switch Activates Series Wiring Option in Middle Pickup Position
