Expressive Keybed with aftertouch
Vibrant 7” Color Touch Screen with Multi Touch & Gestures
Sounds Button for Fast Browsing
25 Cutting-edge Instrument Plugins
Powerful 128 Track Midi Sequencer
Assignable Touch Strip Controller
16 RGB Velocity-Sensitive MPC Drum Pads with Note Repeat
2 Mic/Line Inputs with high-end preamps
Audio Interface with high-quality AD/DA converters
Accepts Class Compliant Audio Interfaces and MIDI devices
Onboard Wi-Fi/Bluetooth
4 Assignable Q Link Controller knobs
4GB Ram / Quad Core ARM Processor / 32 GB Internal Storage
Pitch Bend/Modulation Wheels
Dedicated Transport Section
4 Discrete Line Outputs
8 Audio Tracks
8 CV/Gate Output Jacks for modular integration
KEY SPECS
KEYS
61 semi-weighted, full-size keys with aftertouch
PADS
(16) velocity- and pressure-sensitive pads, RGB-backlit
(8) banks accessible via Pad Bank buttons
KNOBS + PERFORMANCE CONTROLS
(4) 360° touch-sensitive Q-Link knobs for parameter adjustment
(1) Touch Strip multi-function 5.5" (140 mm) touch-capacitive controller with LED indicators
360° encoder for display navigation and selection via push
(2) Pitchbend and Mod Wheel
(3) 270° knobs for gain, mix & level adjustment
BUTTONS
(44) dedicated-function buttons
DISPLAY
6.9” / 176 mm (diagonal)
5.9” x 3.7” / 150 x 93 mm (width x height)
Full-color LED-backlit display with touch interface
MEMORY
RAM 4 GB
Internal storage 32 GB (user storage, 13 GB pre-installed content), 4 GB (MPC operating system), 15+ GB free-space for user storage
expandable via SATA connections
POWER
Via IEC (Included)
Auto Switching Internal Power Supply (100-240v)
CONNECTIONS
(2) XLR+1/4” (6.35 mm) TRS inputs (Input 1/2)
(4) 1/4” (6.35 mm) TRS outputs (2 stereo pairs)
1/4” (6.35 mm) stereo headphone output
(1) 5-pin MIDI input
(1) 5-pin MIDI output
(1) 5-pin MIDI thru
(8) 1/8” (3.5 mm) CV/Gate outputs
Ethernet Network port
USB Type-A ports
(1) USB Type-B port
OTHER CONTROLS
(2) Line | Instrument switches
+48v Phantom Power switch
1/4” (6.35 mm) TRS Footswitch jacks (Sustain + FS2)(Variable and switch compatible)
1/4" (6.35 mm) TRS Expression Pedal input
