MICROPHONE INPUTS
Frequency Response
20Hz - 20kHz +0.5/-1.5dB
Dynamic Range
109 dB (A-Weighted)
THD+N
<0.001%
Noise EIN
-127 dBu
Maximum input level (without pad)
+8 dBu
Maximum input level (with pad)
+16 dBu
Gain Range
50 dB
Input Impedance
3 kΩ
LINE INPUTS
Frequency Response
20Hz - 20kHz +0.5/-1.5dB
Dynamic Range
109 dB (A-Weighted)
THD+N
<0.002%
Maximum input level
+22 dBu
Gain Range
50 dB
Input Impedance
49 kΩ
INSTRUMENT INPUTS
Frequency Response
20Hz - 20kHz +0.5/-1.5dB
Dynamic Range
108 dB (A-Weighted)
THD+N
<0.01%
Maximum input level
+13 dBu
Gain Range
50 dB3
Input Impedance
1 MΩ
Maximum Output Level (0 dBFS)
+16dBu @ 0dBFS, or >21dBu where ADAT output is not used
THD+N
<0.001%
Ouput Impedance
136 Ω (Balanced) - for units with serial number ≤ W960065003383
576 Ω (Balanced) - for units with serial number > W960065003383
