Cond. construction: stranded bare copper, 28 x 0.15 mm
Cond. cross section: 0.50 mm²
Insulation: polyethylene (PE)
Core Arrangement: 2 cores twisted to a pair
Inner Jacket: extruded inner covering from PVC
Shielding: double, counter-rotating, bare copper spiral Shield
Outer Jacket: PVC
Overall Diameter: 7.0 mm
Mechanics
Min. Bending Radius: 35 mm
Working temperature: -20°C / +70°C
Electric
Conductor Resistance: < 40 Ω/km
Capacitance:
Cond./Cond.: 55 pF/m
Cond./Shield: 95 pF/m
Insulation Resistance: > 0.1 GΩ x km
