Audio-Technica ES947/LED Cardioid Condenser Microphone

SKU: E-6-424

Category:
Pro-Audio

Sub-Category:
Microphones

With its low-profile design that mounts unobtrusively in tabletops for minimum visibility, the ES947/LED cardioid condenser boundary microphone provides clear, highly intelligible audio that is perfect for sound reinforcement, professional recording and teleconferencing, television and other demanding sound pickup applications.

PHP 16,000.00

This product is currently out of stock.

Protected by a rugged all-metal case with a two-layer steel mesh grille, the microphone's cardioid polar pattern affords a 120° pickup angle, while its UniGuard RFI-shielding technology provides outstanding rejection of radio frequency interference (RFI). Users can easily toggle between mute and live audio thanks to the microphone's capacitive-type touch-sensitive switch. An integral Red/Green LED ring indicates the mute status, staying green when the microphone is live and turning red when it is muted.

Additionally, the ES947/LED is equipped with a self-contained power module with an XLRM-type output connector, eliminating the need for an external power module.

The microphone is available in two colors: black (ES947/LED) and silver (ES947SV/LED). A pair of isolators is included for optional mechanical isolation from the mounting surface.

Features:
Mounts unobtrusively in tabletops
Capacitive-type touch-sensitive switch allows users to easily mute/un-mute the microphone
Integral LED ring indicates mute status - stays green when mic is live, turns red when muted
Low-profile element provides uniform cardioid polar pattern with 120° acceptance angle
Self-contained power module with XLRM-type output connector
UniGuard RFI-shielding technology offers outstanding rejection of radio frequency interference (RFI)
Requires 11V to 52V DC phantom power
Rugged all-metal case with a two-layer steel mesh grille
Isolators provide mechanical dampening of mounting surface vibration

Microphones:
Element: Fixed-charge back plate, permanently polarized condenser
Polar Pattern: Half-cardioid (cardioid in hemisphere above mounting surface)
Frequency Response: 40-13,000 Hz
Open Circuit Sensitivity: -40 dB (10 mV) re 1V at 1 Pa
Maximum Input Sound Level: 142 dB SPL, 1 kHz at 1% T.H.D.
Dynamic Range: 114 dB, 1 kHz at Max SPL
Signal-to-Noise Ratio: 66 dB, 1 kHz at 1 Pa
Phantom Power Requirements: 11-52V DC, 5.7 mA typical
Switches: Touch-sensitive control: on/mute
Weight: 66 g (2.3 oz)
Dimensions: 84.8 mm (3.33") long,
38.0 mm (1.49") diameter
48.0 mm (1.89") maximum width
Output Connector: Integral 3-pin XLRM-type

Accessories: Included One pair isolators
