SPECIFICATIONS:
Overall System:
Operating Frequencies Band L: 575.000 to 608.000 MHz, 1321 frequencies
Band M: 614.000 to 647.000 MHz, 1321 frequencies
Bande H1: 754.000 to 787.000 MHz, 1321 (nombre de fréquences)
(Not all frequency bands available in all areas. Please check with local regulations)
Minimum Frequency Step : 25 kHz
Modulation Mode : FM stereo
Maximum Deviation : ±40 kHz
Simultaneous Use : 16 channels per band (maximum recommended)
Frequency Response : 60 Hz to 13 kHz (+/- 3 dB)
Operating Range: 100 m (300'), typical (Open range environment with no interfering signals.)
Dynamic Range : 90 dB (typical), A-weighted
Total Harmonic Distortion : <1% at (1 kHz, ±20 kHz Deviation)
Operating Temperature Range : -5° C (23° F) to +50° C (122° F) (Battery performance may be reduced at very low temperatures.)
Receiver
Receiving System : Double conversion superheterodyne
Sensitivity : 20 dBuV (at 60 dB S/N ratio, 50 ohms termination)
Headphone Output : 3.5 mm TRS stereo phone jack, 65 mW (at 32 ohms)
Antenna Input : SMA-type, 50 ohms
Battery Type : 2 x 1.5V AA (not included)
Battery Current/Life : 8 hours (alkaline) (Depending on battery type and use pattern)
Dimensions : 70.0 mm (2.76") W x 25.0 mm (0.98") D x 110.0 mm (4.33") H
Weight: 133g, without batteries
Accessories Included: EP3 earphone; flexible antenna
Transmitter:
Power Output: 10 mW/50 mW (switchable), 50 ohms Limited to 10 mW within 863 MHz to 865 MHz
Spurious Emissions: Following national regulations
Input Connection: XLRF-type/6.3 mm stereo (1/4") combination connector Pin 1 and Sleeve: Ground Pin 2 and Tip: Hot Pin 3 and Ring: Cold
Maximum Input Level : XLRF-type/6.3 mm stereo, (1/4") balanced: +26 dBu 6.3 mm (1/4") mono, unbalanced: +26 dBu
Loop Output Connection: XLRM-type connector Pin 1: Ground Pin 2: Hot Pin 3: Cold
Power Requirement: 12-18V DC, 600 mA
Headphone Output Connector: 6.3 mm (1/4") TRS stereo phone jack
Headphone Output Power: 120 mW at 32 ohms
Antenna Connector: BNC, 50 ohms
Dimensions: 210.0 mm (8.30") W x 132.0 mm (5.20") D x 44.0 mm (1.70") H
Net Weight: 930g, without accessories
Accessories Included: AC adapter (country dependant); rack mount adapters; flexible antenna
